557061

557058（中国销售）

Certifications

CE

CE

Control Modes

Volume

Volume

Depth English

17.25 in

17.25 in

Depth Metric

43.8 cm

43.8 cm

Display

2 line x 20 character VFD display

2 line x 20 character VFD display

External Trigger

+5 to +12 V peak pulse

+5 to +12 V peak pulse

Gas Supply

Room air or non-flammable mixed gas

Room air or non-flammable mixed gas

Height English

8.0 in

8.0 in

Height Metric

20.3 cm

20.3 cm

I E Ratio

1:4 to 4:1 %

1:4 to 4:1 %

Inspiratory Flow

0 to 12 SLPM

0 to 12 SLPM

Inspiratory Hold Time Full Range

1 to 120 sec

Not available

Inspiratory Hold Time Safe Range

1 to 60 sec

Not available

Model

Inspira ASVV-IH

Inspira ASVV

Net Weight English

20 lb

20 lb

Net Weight Metric

9.1 kg

9.1 kg

Number of Animals

1

1

PEEP

Built in machine

Built in machine

Port Size English OD

1/16, 1/8, 5/32 or 3/16 in adjustable

1/16, 1/8, 5/32 or 3/16 in adjustable

Port Size OD Metric

1.75, 3.5, 4.1 or 5 mm adjustable

1.75, 3.5, 4.1 or 5 mm adjustable

Pressure Range

0 to 50 cmH2O

0 to 50 cmH2O

Pressure Signal

0 to 5 V Analog

0 to 5 V Analog

Pressure Signal Note

(representing 0 to 50 cmH20)

(representing 0 to 50 cmH20)

Resolution

1 breath/min

1 breath/min

Respiration Rate Maximum

200 breaths/min

200 breaths/min

Respiration Rate Minimum

5 breaths/min

5 breaths/min

Respiratory Assist

Not available

Not available

Sigh Frequency

Auto or manual

Auto or manual

Sigh Pressure

Not available

Not available

Signal Inputs

External trigger

External trigger

Signal Output

Sync out, 2 analog outputs (user selectable)

Sync out, 2 analog outputs (user selectable)

Species

Mice, Rats, Guinea Pigs, Rabbits, Cats

Mice, Rats, Guinea Pigs, Rabbits, Cats

Tidal Volume Maximum

100 ml/stroke

100 ml/stroke

Tidal Volume Minimum

0.1 ml/stroke

0.1 ml/stroke

Voltage Range

170 to 264 V, AC 85 to 132 V, 50/60 Hz

170 to 264 V, AC 85 to 132 V, 50/60 Hz

Weight Range Maximum

10 kg

10 kg

Weight Range Minimum

15 g

15 g

Width English

10.0 in

10.0 in

Width Metric

25.4 cm

25.4 cm
