产品名称
|
NanoDrop OneC Microvolume UV-Vis Spectrophotometer with Wi-Fi
|
NanoDrop One Microvolume UV-Vis Spectrophotometer with Wi-Fi
|
|
产品货号
|
ND-ONEC-W
|
ND-ONE-W
|
|
应用
|
Nucleic Acid A260, A260/A280, A260/A230 and Labeled Nucleic Acids; Protein A280 and A205, Protein Pierce 660, Protein Bradford, Protein BCA, Protein Lowry, Labeled Proteins, OD600, Kinetics, UV-Vis, and Custom Methods
|
Nucleic Acid A260, A260/A280, A260/A230 and Labeled Nucleic Acids; Protein A280 and A205, Protein Pierce 660, Protein Bradford, Protein BCA, Protein Lowry, Labeled Proteins,OD600, Kinetics, UV-Vis, and Custom Methods
|
|
认证/合规
|
All NanoDrop instruments are approved to CE and UL/CSA.
|
All NanoDrop instruments are approved to CE and UL/CSA.
|
|
兼容性
|
DYMO LabelWriter 450 printer, Bluetooth keyboard, mouse and barcode reader
|
DYMO LabelWriter 450 printer, Bluetooth keyboard, mouse and barcode reader
|
|
浓度
|
Maximum dsDNA: Pedestal: 27,500 ng/µL BSA (IgG): Pedestal: 820 (400) mg/mL
|
MaximumdsDNA: Pedestal: 27,500 ng/µLBSA (IgG): Pedestal: 820 (400) mg/mL
|
|
连接
|
Three USB-A ports, Ethernet, Bluetooth™ and Wi-Fi (Only available on instruments with Wi-Fi/Bluetooth support)
|
Three USB-A ports, Ethernet, Bluetooth™ and Wi-Fi(Only available on instruments with Wi-Fi/Bluetooth support)
|
|
描述
|
NanoDrop OneC Microvolume UV-Vis Spectrophotometer with Wi-Fi
|
NanoDrop One Microvolume UV-Vis Spectrophotometer with Wi-Fi
|
|
检测范围
|
dsDNA: Pedestal: 2.0 ng/µL; Cuvette: 0.2 ng/µL BSA (IgG): Pedestal: 0.06 (0.03) mg/mL; Cuvette: 0.006 (0.003) mg/mL
|
dsDNA: Pedestal: 2.0 ng/µL; Cuvette: 0.2 ng/µLBSA (IgG): Pedestal: 0.06 (0.03) mg/mL; Cuvette: 0.006 (0.003) mg/mL
|
|
检测器类型
|
2048-element CMOS linear image sensor
|
2048-element CMOS linear image sensor
|
|
Dimensions (L x W x H)
|
20 x 25.4 x 32.3 cm (8 x 10 x 12.7 in.)
|
20 x 25.4 x 32.3 cm (8 x 10 x 12.7 in.)
|
|
显示
|
7-inch, 1280 x 800 high-definition color display
|
7-inch, 1280 x 800 high-definition color display
|
|
键盘
|
Built-in touchscreen, multipoint capacitive touch
|
Built-in touchscreen, multipoint capacitive touch
|
|
灯
|
Xenon flash lamp
|
Xenon flash lamp
|
|
语言
|
English, Spanish, Polish, Korean, Japanese, German, French, Chinese
|
English, Spanish, Polish, Korean, Japanese, German, French, Chinese
|
|
测量时间
|
Measurement and Data Processing Time 8 seconds
|
Measurement and Data Processing Time 8 seconds
|
|
操作系统
|
Android™
|
Android™
|
|
路径长度（公制）
|
0.030 to 1.0 mm auto-ranging
|
0.030 to 1.0 mm auto-ranging
|
|
Photometric Accuracy Instrument
|
3% at 0.97 A, 302 nm (Absorbance expressed at Abs/mm at 25°C)
|
3% at 0.97 A, 302 nm(Absorbance expressed at Abs/mm at 25°C)
|
|
Photometric Range
|
10 mm equivalent: Pedestal: 0–550 A; Cuvette: 0–1.5 A
|
10 mm equivalent: Pedestal: 0–550 A; Cuvette: 0–1.5 A
|
|
功耗
|
Operating: 12–18 W Standby: 5 W
|
Operating: 12–18 WStandby: 5 W
|
|
重复性
|
Measurement repeatability: Typical: 0.002 A (1.0 mm path) or 1%CV, whichever is greater (SD of 10 individual measurements at 0.97 A)
|
Measurement repeatability: Typical: 0.002 A (1.0 mm path) or 1%CV, whichever is greater(SD of 10 individual measurements at 0.97 A)
|
|
样品温度
|
Temperature Control (cuvette only) 37 °C
|
Temperature Control (cuvette only) 37 °C
|
|
样品体积（公制）
|
Minimum 1µL
|
Minimum 1µL
|
|
光谱带宽
|
≤1.8 nm (FWHM at Hg 254 nm)
|
≤1.8 nm (FWHM at Hg 254 nm)
|
|
系统要求
|
Windows™ 8.1 and 10, 64 bit
|
Windows™ 8.1 and 10, 64 bit
|
|
电压
|
12 V (DC)
|
12 V (DC)
|
|
波长精度
|
±1 nm
|
±1 nm
|
|
波长范围
|
190–850 nm
|
190–850 nm
|
|
重量（英制）
|
7.9 lbs.
|
7.9 lbs.
|
|
重量（公制）
|
3.6 kg
|
3.6 kg
|
