| 订货号 |
型号 |
温度范围 |
制冷功率 |
工作区域(长x 宽x高) |
净重 |
电源要求 |
功率 |
| 322-1202 |
EK20 |
-25° to +150°C |
300w at +20°C; 150w at -10°C |
46 x 23 x 38cm (18.1 x 9 x 15 in.) |
22kg (48.5 lb.) |
115V 60Hz |
160w |
| 322-1201 |
EK20 |
-20° to +150°C |
300w at +20°C; 150w at -10°C |
46 x 23 x 38cm (18.1 x 9 x 15 in.) |
22kg (48.5 lb.) |
230V 50/60Hz |
160w |
| 323-1302 |
EK30 |
-30° to +150°C |
400w at +20°C; 250w at -10°C |
46 x 23 x 38cm (18.1 x 9 x 15 in.) |
23kg (50.7 lb.) |
115V 60Hz |
270w |
| 323-1301 |
EK30 |
-30° to +150°C |
400w at +20°C; 250w at -10°C |
46 x 23 x 38cm (18.1 x 9 x 15 in.) |
23kg (50.7 lb.) |
230V 50/60Hz |
270w |
| 328-1451 |
EK45 |
-45° to +40°C |
350w at +20°C; 250w at -10°C; 50w at -40°C |
46 x 23 x 38cm (18.1 x 9 x 15 in.) |
30kg (66.1 lb.) |
230V 50/60Hz |
300w |
| 328-1452 |
EK45 |
-45° to +40°C |
350w at +20°C; 250w at -10°C; 50w at -40°C |
46 x 23 x 38cm (18.1 x 9 x 15 in.) |
30kg (66.1 lb.) |
115V 60Hz |
300w |
| 328-1462 |
EK45FP
(w/flexible probe) |
-45° to +40°C |
400w at +20°C; 250w at -10°C |
46 x 23 x 38cm (18.1 x 9 x 15 in.) |
30kg (66.1 lb.) |
115V 60Hz |
300w |
| 329-1901 |
EK90 |
-90° to +40°C |
300w at +20°C; 280w at -10°C;
170w at -40°C; 100w at -60°C |
46 x 38 x 49cm (18.1 x 15 x 19.3 in.) |
60kg (132.3 lb.) |
230V 50/60Hz |
750w |
